If your club is at home, the FXM2300USB DJ Mixing Desk is the perfect choice for you to get into DJing at the best budget but with a full set of features, including basic USB connectivity. Three stereo inputs with Kill-EQs and a crossfader make this console very flexible for mixing, while the dedicated microphone input with voice-specific EQ allows proper vocal presentations. Two master outputs, with the main output being balanced, and a configurable, powerful headphone section make this mixer perfect both for beginners as well as Pro’s who just don’t need a club mixer’s number of channels but all its features for their sets at home.


  • 2x switchable Phono (Line)/Line stereo inputs
  • 1x switchable Line/USB stereo input
  • All stereo inputs with Gain, 3-band EQ (+12/-26dB) and 5-LED level meter for greatest ease of setting gain
  • 1x Mic input with versatile Combo connector and voice-specific 2-band EQ plus “on air” switch
  • Smooth dual-rail 60mm channel faders
  • 45mm dual-rail crossfader for channels 1 and 3 with Steep/Flat curve switch
  • Master section with level control and dual level meter
  • Additional Booth output
  • PFL section with PFL/Main mix control and Blend/Split option
  • Powerful headphones output with 6.3mm stereo jack
  • Rear side USB stereo replay/record port (type B)
  • Balanced and unbalanced Main output
  • Unbalanced record output
  • CE/ROHS compliant




  • Signal/Noise >82dB (Line)
  • Crosstalk Damping >65dB (Line)
  • THD <0.07% (Line)
  • Frequency response 20Hz – 20 kHz


  • AC IN (EU version) AC220-250V~ 50Hz
  • AC IN (US version) AC110-120V~ 60Hz
  • Power consumption max. 16W
  • Dimensions W214xH294xD104mm (85mm mounting depth)
  • Weight 2.4 kg



The FXM2300USB can be modified to suit the customer’s needs. The following options are available (only on order – not for retrofit):

  • Knob style and colour (various knob styles available)
  • Cabinet painting colour
  • Silkscreen artwork and colour
  • Packaging artwork
