The FXM4800 DJ Rack Mixer is the choice of those who made the transition from turntables to CDs and MP3s already and/or prefer to take their performance on the road. Packing all the features from our 10’’ models into a sleek, rack-mounted all-metal cabinet delivers exactly what the DJ, host or performer needs on the road or in a small club – from precise gain controls and 3-band EQs in all stereo inputs through two microphone channels with 3-band EQ and adjustable talkover for flawless vocal performances to two separately adjustable master outputs. All thrills but no frills in a compact form factor at a truly appealing price point!


  • 2x switchable Phono (Line)/Line inputs
  • 1x switchable Line/USB input
  • 1x switchable Line/AUX input with the AUX input being a front-panel mounted 3.5mm TRS jack (for easy connection of e.g. MP3 players)
  • All stereo inputs with Gain, 3-band EQ (+12/-26dB) and peak LED for greatest ease of setting gain
  • All stereo inputs assignable to either left or right side of the crossfader or directly to master
  • 2x Mic inputs (1xCombo, 1xTRS) with Gain, 3-Band EQ, and “on air” switch
  • Adjustable Talkover for mic inputs (damping – sensitivity on rear)
  • Smooth dual-rail 60mm channel faders
  • Smooth dual-rail 45mm crossfader with switchable curve “flat”/”steep”
  • Master section with level control and dual level meter
  • Additional booth output
  • PFL section with PFL/Main mix control and Blend/Split option
  • Powerful headphones output with 6.3mm stereo jack
  • Balanced and unbalanced main output
  • Unbalanced record output
  • Compact 19”/4U form factor
  • CE/ROHS compliant



Two USB options are available for the FXM4800USB:

  • Twin-USB option with two USB inputs which can be assigned to channels 1 and 4 (model code FXM4800USB-T)
  • Single-USB option with one USB input which can be assigned to channel 1 (model code FXM4800USB-S)




  • Signal/Noise >82dB (Line)
  • Crosstalk Damping >65dB (Line)
  • THD <0.07% (Line)
  • Frequency response 20Hz – 20 kHz


  • AC IN (EU version) AC220-250V~ 50Hz
  • AC IN (US version) AC110-120V~ 60Hz
  • Power consumption max. 18W
  • Dimensions W483xH178xD104mm (85mm mounting depth)
  • Weight 3.2 kg



The FXM4800USB can be modified to suit the customer’s needs. The following options are available (only on order – not for retrofit):

  • Knob style and colour (various knob styles available)
  • Cabinet painting colour
  • Silkscreen artwork and colour
  • Packaging artwork
