As the entry-level model of Prosonar’s consumer-grade Spintec series, the CSM211 Stereo Mixer makes a difference to what a customer can expect from a mixer in this very affordable price range. Other than its competitors, this mixer has input gain controls, proper faders and a microphone tone control. To bring assistance to a perfect mix, the input levels can be displayed on the VU meter and a premix can be done on the headphones. As an extra feature, a top-panel 3.5mm TRS jack accepts input from MP3 players and alike. As an option, the CSM211 can be equipped with an on-board MP3 player to replay files from an USB memory stick instead of the 3.5mm TRS socket. There is no mixer in the market with better value for money!


  • 2x switchable Phono/Line stereo inputs
  • Gain control for two main input channels
  • 1x Line stereo input with top-panel 3.5mm TRS stereo socket (version without MP3 player)
  • 1x microphone input on rear-side 6.3mm TRS socket
  • Tone control for microphone input
  • 45mm smooth channel faders and crossfader
  • 1 Stereo master output
  • Manual Talkover for microphone input which reduces master music level by 20dB for the time the “talk” switch is pressed
  • 2×5-LED VU meter, assignable between master and split CUE
  • CUE section with volume control and PFL/Main mix control
  • Headphones output with 6.3mm rear-side stereo jack
  • Unbalanced record output
  • External 12V AC power adaptor
  • All-metal case
  • CE/ROHS compliant

Optional MP3 Player

Instead of the top-panel 3.5mm TRS stereo input jack, a 3-button operated MP3 player can be fitted (no retrofit possible – must be factory-fitted), allowing to play MP3 files from an USB stick (max. 32GB).




  • Signal/Noise >75dB (Line)
  • Crosstalk Damping >60dB (Line)
  • THD <0.07% (Line)
  • Frequency response 20Hz – 20 kHz


  • AC IN (EU version) AC220-250V~ 50Hz
  • AC IN (US version) AC110-120V~ 60Hz
  • Power consumption max. 4W
  • Dimensions W180xH135xD58mm (39mm mounting depth)
  • Weight 0.9 kg



The CSM211 can be modified to suit the customer’s needs. The following options are available (only on order – not for retrofit):

  • MP3 player for USB sticks (max. 32GB) instead of AUX input
  • Knob style and colour (various knob styles available)
  • Cabinet painting colour
  • Silkscreen artwork and colour
  • Packaging artwork
