As the smallest member of Prosonar’s new “Turntablist” series, the TSM221 2-channel-mixer packs all essential features in a compact yet sturdy full-metal case, and is ready to take a DJ’s skills right to the dancefloor! While care has been taken to optimize cost, no compromise has been made in terms of features or performance: two stereo inputs with Kill-EQs and a crossfader with adjustable curve are accompanied by a comprehensive prelistening section and a fully-featured microphone input. A balanced master output allows to feed a sound system with professional connectivity. Unlike other mixers of its class, the TSM221 sports an internal power supply, making it superior in audio dynamics to most of its contestants.


  • 2x switchable Phono (Line)/Line stereo inputs
  • Stereo inputs with gain control and 3-band EQ (+12/-26dB)
  • 1x Mic input with XLR input connector and voice-specific 2-band EQ plus “on air” switch
  • Smooth 45mm channel faders
  • 45mm dual-rail crossfader with Steep/Flat curve switch
  • Crossfader front-detachable
  • Master section with level control and dual 10-LED “neon-flow” level Meter
  • Master level meter assignable to CH1/CH2 input level for gain adjustment
  • PFL section with level control and seamless PFL/Main mix function
  • Powerful headphones output with 6.3mm stereo jack on front side of unit
  • Balanced and unbalanced Main output
  • Internal symmetrical power supply for high audio dynamics
  • CE/ROHS compliant




  • Signal/Noise >82dB (Line)
  • Crosstalk Damping >65dB (Line)
  • THD <0.07% (Line)
  • Frequency response 20Hz – 20 kHz


  • AC IN (EU version) AC220-250V~ 50Hz
  • AC IN (US version) AC110-120V~ 60Hz
  • Power consumption max. 16W
  • Dimensions W176xH265xD88mm (69mm mounting depth)
  • Weight 2.4 kg



The TSM221 can be modified to suit the customer’s needs. The following options are available (only on order – not for retrofit):

  • Knob style and colour (various knob styles available)
  • Cabinet painting colour
  • Silkscreen artwork and colour
  • Packaging artwork
